Astronomy Specialist

ZWO ASI678MC [COLOUR]

$539.00 AUD
SKU: ASI678MC

ZWO

47.5 FPS

12-bit

7.68 x 4.32 mm

2.0 µm




The ZWO ASI 678MC is a professional colour planetary camera containing the Sony STARVIS 2 IMX678 CMOS backlit colour sensor which has a diagonal of 1/1.8" and a resolution of 8.29 MP with 2.0µm pixels. The 678MC can be considered a successor to the ASI 178MC, with zero amp glow, lower dark current noise and lower read noise.





The sensor has a maximum QE up to 83%. This high sensitivity across the visible and near IR light spectrum and very low readout noise make it ideal for high resolution planetary imaging.




The USB 3.0 Port provides 5Gbps bandwidth and lets the camera run at 47.5fps (12bit, normal mode) at full resolution (8.29 Megapixels). Frame rate can be limited by the power of the computer and the writing speed of your hard disk. For higher performance it is suggested to use Solid State Drives.

The ASI678MC has a HCG mode which effectively reduces readout noise at high gain settings while preserving the same wide dynamic range that you would get at low gain. From 80 gain and higher, HCG mode will automatically activate, giving a read noise as low as 1.0e- with a dynamic range of 12 stops.




The ASI678MC has built-in anti-amp glow circuitry which is implemented directly at the hardware level.



Sensor
1/1.8″ CMOS Sony-IMX678AAQR1-C
Resolution
8.29 Megapixels, 3840 x 2160
Pixel size
2.0 µm
Sensor size
7.68 x 4.32 mm, 8.86 mm diagonal
Bayer pattern R Gr Gb B
Quantum efficiency
83%
Exposure range 32 µs - 2000 s
Read noise 0.6 e- to 2.7 e-
Full well capacity 11,270 e-
Bit rate 12 bit
Speed 47.5 fps at full resolution
Shutter type Rolling shutter
ROI Supported
Compatibility Mac, Windows, Linux
Protecting window AR coated
Ports USB 3.0 Type-B, ST4
Back focus 12.5 mm
Connections 2" / 1.25" / M42 x 0.75
Dimensions Ø 62 mm; ↨ 37.1 mm
Weight 126 g
SKU ASI678MC





Customer Reviews

Based on 1 review
100%
(1)
0%
(0)
0%
(0)
0%
(0)
0%
(0)
K
Kevin Parker
Great camera

I upgraded from an Svbony SV305 (290mc) to the ZWO ASI 678mc. I like how easy it is to get a good image scale with it's 2um pixels and a 2X barlow on an F5 12" scope. Even at F14 it still performs. The camera is also great for satellite and meteor hunting. It will even do some deep sky, although there are better cameras made for that purpose.

Testar were also VERY fast with service. Couldn't ask for more.
