ZWO ASI 533MC PRO [COLOUR]
The ZWO ASI 533MC PRO is a cooled camera with great performance for a very competitive price.
The ZWO ASI 553MC contains the Sony IMX533 CMOS colour sensor which has a diagonal of 15.99mm and a resolution of 9 MPx. The Sony back-illuminated sensor technology improves sensitivity and reduces the noise for the best performance.
The ZWO PRO cameras incorporate a 256MB DDR3 memory buffer that improves data transfer reliability and it minimizes amp-glow caused by slow data transfer speeds.
A higher QE means more of the light is converted into signal. The ASI 533MC has a maximum QE of 80%.
The USB 3.0 Port provides 5Gbps bandwidth and lets the camera run at 20fps at full resolution.
The USB 2.0 Hub allows to connect 2 USB controlled accessories such as a filter wheel, a guiding camera or an electronic focuser, reducing the amount of cables that run directly from your computer.
The thermo electric cooling system allows a ΔT of 40°CC below ambient. The cooling system requires an external power supply of 12V at 3-5A with a 2.1×5.5mm connector (positive tip). The ASI 533MC can be powered with a standard lead battery or a DC source between 9-15V.
The dark current of the ASI533MC is extremely low, based on our test results.
Traditional CMOS sensors emit a weak infrared light and quite often it is seen in the corner of uncalibrated images. This is called "amp glow". The ASI533MC PRO uses a zero amp glow circuitry which eliminates the problem, even when using high gain and a long exposure.
With amp glow – exposure of 300 seconds:
ASI553 frame with no amp glow – exposure of 300 seconds:
| Sensor |
1″ CMOS Sony IMX533 - colour |
|
Resolution |
9 megapixels 3008 x 3008 |
|
Pixel size |
3.76 µm |
|
Sensor size |
13.2 mm x 8.8 mm (16 mm diagonal) |
|
Quantum efficiency |
80% |
|
Exposure range |
TBA |
|
Read noise |
1.0 e (@ 30 dB) |
|
Full well capacity |
50,000 e |
|
Bit rate |
14 bit |
|
Speed |
20 fps |
|
Shutter type |
Rolling shutter |
|
Cooling |
ΔT of 40°C |
|
Memory buffer |
256Mb DDR III |
|
ROI |
Supported |
|
Compatibility |
Mac, Windows, Linux |
|
Protecting window |
AR coated |
|
Ports |
USB 3.0 / USB 2.0 |
|
Back focus |
6.5 mm |
|
Connections |
2" / 1.25" / M42 x 0.75 |
|
Dimensions |
Ø 78 mm; ↨ 77.5 mm |
|
Weight |
TBA |
|
Power supply |
9-15V 3 A (2.1×5.5 mm connector) |
|
SKU |
ASI533MC-P |
- Camera bag
- Camera body
- USB 3.0 cable (2 metres)
- 21mm extender (M42 male - M42 female)
- 16.5mm extender (M48 female - M42 male)
- 11mm M42 female extender (screwed to the camera)
- Nose piece (M42 male to 1.25" female)
- Internal adapter M42 (female) to M48 (male)
- 2x USB 2.0 cables 0.5m
- M42 male to 1.25" filter thread (necessary to connect a 1.25" filter inside the 11mm extender)
- 0.3mm spacer
- 0.5mm spacer
- User manual
- 1.25mm plastic cap
- Plastic cap for 11mm M42 extender
