Astronomy Specialist

TOUPTEK G3M 662C PLANETARY CAMERA [COLOUR]

Regular price $399.00AUD
SKU: TT-G3M662C

ToupTek

FREE SHIPPING




The ToupTek G3M662C Planetary Colour is a 1.25" barrel size planetary camera using the Sony IMX662C CMOS sensor. With a quantum efficiency of >91%, read noise as low as 0.46e- and 2.9µm pixels, the G3M662C is an excellent camera for high resolution planetary imaging with a wide range of telescopes.




The G3M662C's back-illuminated sensor has QE up to 91% and very good NIR sensitivity, making it possible to use IR-pass filters to cut through the atmosphere and bring out finer details.

Note: in order to attach 1.25" filters to Touptek G3M series planetary cameras, you must use the included 1.25" barrel extender. The standard CS adapter does not have the necessary M28.5 filter threads.





The G3M662C is equipped with USB 3.0 connectivity as well as a traditional ST-4 autoguiding interface. Thanks to the high transmission speed of USB 3, the G3M662C can reach an incredibly fast 152FPS at full resolution. The built-in 512MB DDR3 memory ensures reliability over long sequences of high framerate video capture. Its 1.25" barrel design also makes it straightforward to use with most off-axis guiders (OAG not included).

Available in anodized Red.

Specifications

Sensor

CMOS Sony IMX662C colour

Resolution

2.1 megapixels 1920 x 1080

Pixel size

2.9 µm

Sensor size

5.57 mm x 3.13 mm (6.39 mm diagonal)

Quantum efficiency

>89%

Exposure range

0.1 ms - 1000 s

Read noise

0.49 e-

Full well capacity

11,800 e-

Bit rate

12 bit

Speed

152 fps

Shutter type

Rolling shutter

ROI

Supported

Compatibility

Windows, Mac, Linux

Protecting window

AR coated

Ports

USB 3.0 + ST-4

Back focus

12.5 mm

Connections

C/CS-mount, 1.25" barrel

Dimensions

Ø 37 mm; ↨ 87.4 mm

Weight

TBD

Power supply

USB 3.0

SKU

TT-G3M662C




Items included


  • Camera body
  • USB 3.0 cable
  • ST-4 cable (2 metres)
  • 1.25" extender

Downloads


 ToupTek software and drivers

 User manual
