TOUPTEK IMX410 SKYEYE 24AC PRO CAMERA [COLOUR]

$4,299.00 AUD
SKU: TT-SkyEye24AC

ToupTek

15.2 FPS

14-bit

36.02 x 23.99 mm

5.94 µm




The ToupTek SkyEye 24AC PRO IMX 410C Colour is a cooled astronomy camera using the Sony IMX410 full-frame 14-bit back-illuminated CMOS sensor. With a quantum efficiency of >80%, read noise as low as 1.95e- and large 5.94µm pixels, the SkyEye 24AC is a highly capable deep sky camera for long focal length telescopes.





The camera features large 5.94µm pixels and a resolution of 24MP. The large full-well capacity of 104ke- means you can capture faint targets without overexposing stars. The SkyEye 24AC is equipped with 5Gbps USB 3.0 connectivity and 512MB of DDR3 memory resulting in fast transfer speeds and reliability.





The ToupTek SkyEye 24AC has zero amp glow, even at high gain and over long exposure times. The below image shows two 5-minute exposures at 20°C with different cameras. The ToupTek image on the right shows no visible amp-glow. Combined with its low dark current and powerful TEC cooling to -35°C below ambient, the camera is capable of teasing out fine details of faint nebulae.





The SkyEye 24AC features a built-in dew heater around the protective window with 4 levels of adjustable heating power. The camera includes an integrated two port USB 2.0 hub, allowing you to connect guide cameras, electronic focusers, filter wheels and other accessories.




Sensor

Full-frame CMOS Sony IMX410 colour

Resolution

24 megapixels 6064 x 4040

Pixel size

5.94 µm

Sensor size

36.02 mm x 23.99 mm (43.3 mm diagonal)

Quantum efficiency

>80%

Exposure range

TBD

Read noise

1.95 e-

Full well capacity

104,000 e-

Bit rate

14 bit

Speed

15.2 fps in 8-bit full resolution, 8 fps at 14-bit full resolution

Shutter type

Rolling shutter

Cooling

ΔT of 35°C

Memory buffer

512MB DDR3

ROI

Supported

Compatibility

Windows, Mac, Linux

Protecting window

AR coated

Ports

USB 3.0 + USB 2.0 hub

Back focus

17.5 mm

Connections

M54 x 0.75

Dimensions

Ø 89 mm; ↨ 103 mm

Weight

TBD

Power supply

12V 3 A  (2.1×5.5 mm  connector)

SKU

TT-SkyEye24AC





  • Camera body
  • USB 3.0 cable (1.5 metres)
  • 21mm M54 male - M48 female adapter
  • 16.5mm extender M48 male - M48 female
  • M48 to M42 step up ring
  • Wrench
