Astronomy Specialist

OFFICINA STELLARE RiFAST 300 F/3.8

$26,500.00 AUD
SKU: OS-RIFA300SGC

Officina Stellare

RiFAST

300 mm

f/3.8

1140 mm

20 kg




The RiFAST 300 is an astrograph with a new revolutionary optical design proprietary of Officina Stellare, designed by Massimo Riccardi.



OPTICAL DESIGN

The primary mirror is aspherical and the secondary mirror is spherical, a precise design to make collimation easier. The RiFAST includes a 3 elements flattener of which 2 are aspherical and it is placed near the focus position to avoid any chromatic aberration.

The telescope is a native f/3.8 with a flat field up to 60mm. The scope has the option to be used with a dedicated 0.78x reducer (XTFR078) or a 1.5x extender (XTFE15-300).




f/

Focal length

Corrected Field

MBFL

RiFAST 300 without any optical accessories

3.8

1140 mm

60 mm

125 mm

RiFAST 300 with optional 0.78x reducer

3

889 mm

42 mm

68.5 mm

RiFAST 300 with optional 1.5x extender

5.7

1710 mm

42 mm

170.1 mm



MECHANICAL PERFORMANCE


The collimation is stable as ever before due to an improved mechanical design.
Every RiFAST is tested under the sky and is tested in Officina Stellare's factory, ensuring a perfect collimation.


The secondary mirror can be motorized for focusing, leaving the imaging train fixed as screwed to the backplate, a good solution for heavy cameras and accessories. It is also possible to install a tip-tilt mechanism.

Remote observers can upgrade their RiFAST with optional primary mirror shutters to avoid moisture and dust deposit on the telescope’s mirror when not in use.





Optical design

RiFAST

Diameter

300 mm

Focal length

1140 mm

Focal ratio

f/3.8

Linear obstruction

57%

Fully corrected and illuminated field

60 mm

Weight

20 kg

Backfocus extraction

~ 125 mm

SKU

OS-RIFA300SGC

OFFICINA STELLARE RiFAST 300 F/3.8

$26,500.00 AUD

Optical design

RiFAST

Image circle

Focal ratio

f/3.8

Aperture

300 mm

Focal length

1140 mm

Optical thickness

Threads

Cooled

Colour or Mono

Pixel size

Sensor dimensions

Resolution

Sensor diagonal

Quantum efficiency

Read noise

Fullwell capacity

Bit depth

FPS

Camera backfocus

Filter size

Filter size

Bandpass (FWHM)

Bandpass (FWHM)

Glass thickness

Mount type

Payload capacity

Latitude range

Dovetail saddle

Slew speed

Encoders

Periodic error correction

Counterweight shaft

Azimuth adjustment range

Internal diameter

Illuminated diameter

Compatible telescope external diameter

Weight

20 kg

Length

Width

Height

View product
