GSO 6" f/9 RITCHEY-CHRETIEN CARBON OTA

$899.00AUD
SKU: GSRC6CF

GSO

Ritchey-Chrétien

5.2 kg




The Ritchey-Chrétien telescope is the most popular optical design used by professional astronomers and astroimagers all over the world. The Hubble Space Telescope itself uses the RC configuration.

All new GSO RC telescopes now come with an upgraded focuser allowing you to connect the ZWO & QHY EAF focusers without additional modification.

The Guan Sheng Optical RC's are excellent astrographs with solid build quality and precisely-figured optical surfaces. The concave hyperbolic primary and convex secondary mirrors deliver excellent correction across the field. The low thermal expansion quartz mirrors have a surface correction of 1/12th Lambda PV or better and have highly reflective dielectric coatings ensuring 99% reflectivity.

The telescope is made with a lightweight and rigid carbon fibre tube and features computer-optimized baffles to eliminate stray light.

The 6" f/9 Carbon Fibre Ritchey-Chrétien comes with a dual-speed 2" 10:1 Crayford focuser with 41mm of focus travel and includes a 1.25" adapter and a selection of 2" & 1" extension rings to make connecting a variety of imaging accessories straightforward.

The TS-Optics 2" 1x Flattener for RCs is compatible with both the 6" and 8" GSO RC telescopes.

Specifications



Optical design Ritchey-Chrétien
Diameter 152.4 mm
Focal length 1370 mm
Focal ratio f/9
Linear obstruction 76 mm
Corrected field 32 mm
Backfocus distance 159 mm with standard focuser, 254 mm from rear cell
Weight 5.2 kg
Tube outer diameter 191 mm
Tube length 500 mm without focuser
SKU GSRC6CF



Items included



  • GSO 6" f/9 Carbon RC tube
  • 2" dual-speed Crayford focuser
  • Vixen dovetail bar
  • 2 x 1" M90 male to M90 female extension tubes
  • 1 x 2" M90 male to M90 female extension tube
  • Finderscope bracket
  • Dust caps
