The ZWO ASI2600MM PRO uses the back-illuminated Sony ExMor IMX571 APS-C sensor. It features a QE up to 80%, a native bit rate of 16 bits, an ultra-high 14 stops dynamic range and ultra-low 1.0e readout noise.

ZWO ASI2600MM Pro monochrome deep sky cooled CMOS astronomy camera specs

Like the colour version, this camera weighs only 700 grams! The APS-C sensor has the size of 23.5mm x 15.7mm for a diagonal of 28.3mm.

Sony’s back-illuminated CMOS technology improves sensitivity, minimizes noise, reduces power consumption and increases data download speed. In a conventional front-illumination structure, the interconnection of metal wiring and transistors are above the photosensitive silicon surface (photo diode), reducing the overall sensitivity and therefore the quantum efficiency. In back-illuminated sensors, the photosensitive surface is placed on top of the wiring so the incoming light is not obstructed, resulting in a greater quantum efficiency. Sony has developed a new and unique photo-diode structure and an on-chip lens that is optimized for back-illuminated structures, achieving a higher sensitivity and a lower random noise.

The ASI2600MM Pro features a 16bit ADC that can achieve a dynamic range output of 14 stops. This improves the image sharpness and contrast significantly and the colour shades are smoother and more natural.

When the gain value is 100, the HCG high gain mode is automatically activated and the readout noise is greatly reduced while the dynamic range basically remains unchanged.

ZWO ASI2600MM Pro monochrome deep sky cooled CMOS astronomy camera full well, read noise, dark current

The ZWO PRO cameras incorporate a 256MB DDR3 memory buffer that improves data transfer reliability and it minimizes amp-glow caused by slow data transfer speeds.

The USB 3.0 Port provides 5Gbps bandwidth and lets the camera run at 3.51fps at full resolution (26 Mega).

The USB 2.0 Hub allows to connect 2 USB controlled accessories such as a filter wheel, a guiding camera or an electronic focuser, reducing the amount of cables that run directly from your computer.

The 2 stage TEC cooling system allows a ΔT of 35°C below air temperature.

Note: All cooled ZWO cameras require an external power supply of 12V at 3-5A with a 2.1×5.5 mm connector (positive tip).

ZWO ASI2600MM Pro monochrome deep sky cooled CMOS astronomy camera specs dark current

The dew heater avoids the problem of dew condensation on the optical window of the sensor. The heater can be turned off via software.

Traditional CMOS sensors produce a weak infrared light source that is often seen in the corner of uncalibrated images as bright glow. The ASI 2600MM Pro uses the zero amp glow circuits that avert this artefact in your images.

ZWO ASI2600MM Pro monochrome deep sky cooled CMOS astronomy camera amp glow

Amp glow artefact– exposure 300 seconds

ASI 2600MC

ASI2600 frame with no amp glow – Exposure 300 second

Specifications

Sensor	Sony ExMor IMX571 APS-C - mono
Resolution	26 Megapixels 6248 x 4176
Pixel size	3.76 µm
Sensor size	23.5 mm x 15.7 mm (28.3 mm diagonal)
Quantum efficiency	91%
Exposure range	32µs-2000s
Read noise	1.0e ~ 3.3e- (@ 30 dB)
Full well capacity	50,000 e-
Bit rate	16-bit
Speed	3.51 fps
Shutter type	Rolling shutter
Cooling	ΔT of 35°C
Memory buffer	256Mb DDR III
ROI	Supported
Compatibility	Mac, Windows, Linux
Protecting window	D60-2 AR coated
Ports	USB 3.0 / USB 2.0
Back focus	17.5 mm
Connections	2" / 1.25" / M42 x 0.75
Dimensions	Ø 90 mm; ↨ 97 mm
Weight	700 g
Power supply	11-15V 3-5 A (2.1×5.5 mm connector)
SKU	ASI2600MM-P
